Single-Wall Stainless Steel Chimney Systems RENOFAST

RENOFAST — Professional Chimney Systems from Manufacturer Akvilon

RENOFAST is a single-wall stainless steel chimney system designed and manufactured in Latvia. It is the primary choice for renovating existing brick chimneys and connecting boilers, stoves, and fireplaces inside the house.

The system combines manufacturing precision (laser cutting, robotic TIG welding) with high-quality materials, meeting the strictest European standards CE EN 1856-2.

Quick Check: Is RENOFAST right for you?

Before ordering, please ensure this system fits your installation conditions:

Yes, if you have a brick chimney: You want to insert a liner to protect masonry from condensate and improve draft.
Yes, if you need a connection: You need to connect a boiler or stove to a chimney indoors (e.g., in a boiler room).
No, for outdoor installation: Single-wall pipes cannot be used outside or in cold attics. For these areas, use our IZOKOMPAKT insulated double-wall chimneys.

Choose the Right Solution for Your Heater

We cover 100% of flue gas extraction needs by offering three specialized product lines:

Round Systems (Universal)

Best for: Connecting boilers, stoves, and building new internal flue runs.
The classic choice with the best aerodynamics and easy cleaning. Minimal flow resistance prevents soot buildup.

Oval Liners (For Brick Shafts)

Best for: Relining rectangular brick chimneys.
The oval shape allows you to preserve the maximum useful cross-section of a narrow brick shaft where a round pipe would be too small.

RENOFAST T200 (For Gas)

Best for: Modern gas condensing boilers.
A special series with silicone gaskets (Class P1). It guarantees 100% gastightness when working with wet steam and pressure.

Advantages of Buying from Manufacturer

Socket Geometry: We do not use manual forming. All connections are machine-calibrated, ensuring an easy "pipe-in-pipe" fit without gaps.
Stock Program: We keep in stock not only pipes but also complex fittings (tees, elbows, adapters). You can complete your project in one visit.
Honest Steel: We do not compromise on thickness. If 0.6 mm is stated, you get real 0.6 mm of certified AISI 304 or 316L steel.
Direct Price: Buying from Akvilon factory, you avoid dealer markups.

Steel Grades: Which one do I need?

Series	Steel	Suitable for
RENOFAST 600 (Base)	AISI 304 (Chrome-Nickel)	Solid fuel boilers, wood stoves, fireplaces, sauna stoves, ventilation. Excellent heat resistance (up to 600°C).
RENOFAST 600+ (Acid-resistant)	AISI 316L (With Molybdenum)	Liquid fuel boilers (diesel), pellet burners, industrial facilities. Resistant to aggressive acidic condensate.
RENOFAST T200 (Gas-tight)	AISI 304/316 + Gaskets	Gas condensing boilers. Operation under pressure up to 200 Pa at low temperatures (up to 200°C).

System Components

Our catalog contains all necessary parts for a complete installation:

Pipes

Straight sections of 1.0m, 0.5m, and 0.25m. Allow reaching any chimney height with a minimum number of joints.

Fittings

Elbows (Bends): 90° and 45° for changing direction.
Tees: 90° and 45° for boiler connection.

Termination

Cleanouts: Elements with a door for inspection.
Caps: Rain caps, deflectors, and flashings.

Technical Specifications

Parameter	RENOFAST 600 / 600+	RENOFAST T200
Wall Thickness	0.5 / 0.6 / 0.8 / 1.0 mm	0.5 / 0.6 mm
Working Temperature	T600 (up to 600°C)	T200 (up to 200°C)
Working Mode	Negative Pressure (N1)	Positive Pressure (P1)
Corrosion Resistance	Standard (V2) / Acid-resistant (V3)	Moisture-resistant (V2)
Weld Type	Continuous TIG seam (in inert gas environment)

Installation Scheme

The diagram below shows the typical installation of a single-wall liner inside a masonry shaft.

Fig. 1: Installation scheme in a masonry shaft
