Oval Chimney Elbow 90° (Bend on Wide Side) RENOFAST

Description and Purpose

The Single-Wall Oval Elbow 90° is a chimney fitting designed to change the channel direction at a right angle. It is used when installing chimneys of complex configuration, when it is necessary to bypass obstacles or connect equipment.

Geometry Features:

This model features a bend on the wide (flat) side of the oval. This is a specific solution applied when the chimney needs to turn "flat" relative to the wall.

Advantages and Characteristics

• System Compatibility: The elbow is fully compatible with RENOFAST single-wall pipes, ensuring a tight socket connection.
• Smooth Channel: The elbow sectors are welded in such a way as to ensure the smoothest possible flow of flue gases and minimize turbulence.
• Durability: The product is made of acid-resistant stainless steel AISI 304L / 316L, resistant to aggressive condensate and high temperatures.

Technical Specifications

Installation Recommendations

• Space Planning: A turn on the wide side occupies more space (turning radius) than on the narrow side. Consider this when marking the chase or shaft.
• Support: The weight distribution changes with such a turn. Be sure to use wall brackets before and after the elbow to relieve the load from the connections.
• Connection: The element connects with the oval pipe using the "pipe-in-pipe" (socket) method.
