Rigid Roof Bracing Kit 3000 mm
The indicated price is valid ordering till 12.09.2026.
Chimney Rigid Roof Bracing Kit 3000 mm
Description and Purpose
The Rigid Roof Bracing Kit (struts) with a support length of 3000 mm is the maximum fixation set for chimneys rising high above the roof level. The three-meter struts allow anchoring the pipe even when it is located far from the ridge or load-bearing beams, ensuring a shallow and reliable bracing angle.
The construction made of rigid steel profiles creates a powerful structural frame that holds the chimney in a vertical position during storm winds, preventing loosening and destruction of the roof flashing.
When is rigid bracing necessary?
This kit is indispensable if the chimney height above the roof significantly exceeds 1.5 - 2 meters, or if roof conditions require anchoring the supports far from the pipe base.
Kit Contents and Features
- Kit composition:
- Reinforced Mounting Clamp (Fixing Clamp): Installed on the outer casing.
- Two steel profiles (Struts): Length 3000 mm.
- Complete hardware set for assembly.
- Protection and Materials: The product is available in various finishes to protect against corrosion: Galvanized, Powder Coated (RAL 9006), or Stainless Steel (depending on selection).
- Installation: The long 3-meter legs are cut to size on-site. This allows for perfect adjustment of the fastening angle on any, even the most complex, roof geometry.
Technical Specifications
The kit is selected based on the outer diameter of the chimney.
| Product type | Rigid Roof Bracing Kit (Long) |
| Strut length (L) | 3000 mm |
| Material options | Steel S235 or Stainless steel AISI 304 + Galvanized / Painted |
| Tube profile | Reinforced profile (according to diameter and load) |
| Available diameters (outer) | 200, 225, 250, 280, 300 mm |
Other Length Options
If 3 meters is too much for your task, choose more compact versions:
Installation Recommendations
- Roof attachment: Due to the large leverage, the load on the lower attachment points is very high. Fasten supports only to structural wooden roof elements (rafters), passing through the roofing cover.
- Sealing: Carefully seal the fastener entry points into the roof to prevent leaks.
